3 Coils Qi Car Wireless Charger Fast Charger
| Price: | US $ 11-15/Set |
|---|---|
| Min Order: | 100/Set |
| Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: | LQ12-3T |
|---|---|
| Performance Standard: | Qi (WPC) |
| Input Votage (Adptor): | 12V |
| Input Current: | 1A |
| Power: | 5W |
| Conversion Efficiency: | >70% |
| Launch Distance: | 2-8mm |
| PCBA Size: | 55*28*3.5mm |
| Chargering&Current: | DC5V (Output Voltage) |
| Warranty: | 1 Year |
| Character: | 3 Coils |
Product Description
Qi WPC Wireless Car Charger Solution for Dual Coil with KC CE FCCProduct Specification
| Product Name | Car wireless charger module |
| Brand | Aoke |
| Model | LQ 12-3T |
| Wireless Standard | QI (WPC) |
| Applications | Mobile Phone Charger, Car Charger |
| MCU | Sunplus |
| Input votage (Adptor) | DC 12V |
| Input current | 1A |
| Power | 5W |
| Frenquency | 100-200KHz |
| Conversion Efficiency | ≥70% |
| Launch distance | 2-8mm |
| Chargering Current | 500-1000mA (Supply RX) |
| Chargering Votage | DC5V (RX Output Voltage) |
| PCBA Size | 55×28*3.5mm |
| Board thickness | 0.2mm-7mm |
| Oil Size | 43mm*2.2mm |
| Wire Dia | Φ0.08*105p |
| Coil's Out Dia | 20.mm |
| Coil's Inner Dia | 43.5mm±0.5 |
| Coil's thickness | 1.1H±0.5mm |
| Hard Shield specification | 50mm*1mm |
| Solder mask color/Silk color | Green/ white |
| Charging Method | Single |
| Inductance | 4.6uH |
| inductance(add sheild) | 6.0±5%uH |
| Inner Packing | Vaccum Packing, Plastic bag |
| Outer packing | Standard Carton Paking |
Product Photo:
Hot Selling Reason
This PCBA is design for Dual Coil Mobile Phone Charging, can used in Mobile Phone charger, Car Charger. and 2 coil transmitter is better than single coil, because the coil area is bigger, and it charing connect area is more fleixble.
