Home LED Light Products 4 Way DC32V Circuit Car Trailer Auto Blade Fuse Box Block Holder Inline Atc ATO 2-Input 4-Ouput Wire for Bus Ship Tanker Trailer Car Coat
4 Way DC32V Circuit Car Trailer Auto Blade Fuse Box Block Holder Inline Atc ATO 2-Input 4-Ouput Wire for Bus Ship Tanker Trailer Car Coat
| Price: | US $ 1.2-2.2/Piece |
|---|---|
| Min Order: | 50/Piece |
| Pay Type: | T/T,Western Union,Paypal |
| Prod Model: | Fuse Box |
|---|---|
| Type: | Blade Fuse |
| Fuse Holder Installing Method: | In-line Fuse Holder |
| Fuse Holder Size: | M |
| Fuse Holder Material: | Plastic Fuse Holder |
| Application: | BMW |
| Insert Type Fuse Size: | M |
| Bolt Type Fuse Size: | Small |
| Glass Tube Fuse Type: | 6.35?รก30mm |
| Breaking Capacity: | Low |
| Safety Standards: | IEC |
Product Description
4 Way DC32V Circuit Car Trailer Auto Blade Fuse Box Block Holder Inline ATC ATO 2-input 4-ouput Wire for Bus Ship Tanker Trailer Car Coat
4-way fuse box with 6 wires (2 input wires + 4 output wires).Fits for middle size blade fuse (ATC, ATO).
Fits for 12V and 24V equipments (Max voltage: 32V).
Can widely used in bus, ship, tanker, trailer, car, boat, etc.
High quality.
Product description
Size:4 Way
This 4-way fuse box in sturdy construction can be used in automotive electronic field, motorsport applications, electrical devices, trailers, cars, boats, etc. It comes with 6 wires (two input wires and 4 output wires).
Features:
4-way fuse box with 6 wires (2 input wires + 4 output wires).
Fits for middle size blade fuse (ATC, ATO).
Fits for 12V and 24V equipments (Max voltage: 32V).
Can widely used in bus, ship, tanker, trailer, car, boat, etc.
Specifications:
Fitment: for middle size blade plug-in fuse (ATC, ATO)
Color: Black
Way: 4 way
Material: Plastic & Metal
Current: 1A-40A
Max voltage: 32V
Wire quantity: 6 (2 input wires + 4 output wires)
Input wire diameter: approx. 3.8mm /0.15in
Output wire diameter: approx. 3.2mm /0.13in
Mounting hole diameter: approx. 6.5mm /0.26in
Wire length: approx. 14cm / 5.5in
Distance between mounting holes: approx. 5.5cm / 2.2in
Box size: approx. 7.3 * 5.6 * 4.1cm / 2.9 * 2.2 * 1.6in
Item weight: approx. 74g / 2.6oz
Package size: approx. 13.5 * 10.5 * 6.5cm / 5.3 * 4.1 * 2.6in
Package weight: approx. 112g / 3.9oz
Package List:
1 * Fuse Box
*************************************************
