Price: | Negotiable/Piece |
---|---|
Min Order: | 200/Piece |
Pay Type: | T/T,Paypal |
Prod Model: | 5015 |
---|---|
Bearing Type: | Ball Bearing and Sleeve Bearing |
Startup Voltage: | 5V/12V24V |
Speed: | 4000-5500rpm |
Noise: | 28-32dba |
Weight: | 29.00g |
Warranty: | 3 Year for Ball Bearing and 1 Year for Sleeve |
Packing: | Carton |
Delivery Time: | Shipped in 14days After Payment |
Blade Material: | Plastic |
Electric Current Type: | DC |
Certification: | Ce RoHS UL |
Warranty:3 years for ball bearing fans,1 year for sleeve bearing fans | ||||||||
Size: 50*50*15 MM | ||||||||
Model | Rated Voltage (VDC) | Startup Voltage (VDC) | Currend Amp (A) | Speed (rpm) | Air flow (CFM) | Static Pressure (Inch-H20) | Noise Level (dB-A) | Weight (g) |
() | () | () | () | () | () | () | () | () |
XJ05B5015H | 5 | 3.5 | 0.30 | 5500 | 12.40 | 3.82 | 32 | 29.00 |
XJ05B5015M | 5 | 3.5 | 0.25 | 5000 | 10.50 | 3.11 | 30 | 29.00 |
XJ05B5015L | 5 | 3.5 | 0.17 | 4000 | 9.18 | 2.39 | 28 | 29.00 |
XJ12B5015H | 12 | 6 | 0.16 | 5500 | 12.40 | 3.82 | 32 | 29.00 |
XJ12B5015M | 12 | 6 | 0.12 | 5000 | 10.50 | 3.11 | 30 | 29.00 |
XJ12B5015L | 12 | 6 | 0.09 | 4000 | 9.18 | 2.39 | 28 | 29.00 |
XJ24B5015H | 24 | 10 | 0.09 | 5500 | 12.40 | 3.82 | 32 | 29.00 |
XJ24B5015M | 24 | 10 | 0.08 | 5000 | 10.50 | 3.11 | 30 | 29.00 |
XJ24B5015L | 24 | 10 | 0.06 | 4000 | 9.18 | 2.39 | 28 | 29.00 |
Packaging details:
Two layer packaging, pcs/CTNPackaging size:
43*28*43CM
Lead time:
1. Samples within 4 days
2. Mass production within 7-10 days
3. If do the waterproof fan need 1 week more
Express:
Optional functions:
-1. Waterproof function with IP55 or IP67 level
-2.Auto-restart function
-3.Stopage Alarm function(RD function with 3 lead wires)
-4.Speed detection function( FG function with 3 lead wires)
-5.Temperature control speed function(PWM function with 4 lead wires)
Optional bearing types:
-1.Sleeve bearing(lower price):The sleeve was inported from Germany with stalbe performance and easy installation
-2.Ball bearing(high price):we use the NSK ball which is imported from Japan,it is charactered with high quality,low noise level and easy installation.
Guarantee:
-3 years warranty for ball bearing fans
-1 year warranty for sleeve bearing fans
Question & answer:
-1. What kind of cooling fans or centrifugal fans are supplied by your company?
Answer: we can provide DC cooling fan, AC cooling fan, EC cooling fan and blower fan.
-2. What kind of information should be provided by the customer before order?
Answer : please kindly advise Size, Rated voltage, Bearing type, Speed or air flow,Lead wires.
-3. How many kind of bearings for cooling fans are there in your compnay at present?
Answer : now we have two types bearing for the fan, sleeve bearing and ball bearing.
-4. How to detect the data of cooing fan in your company?
Answer: the speed and voltage are detected by the tachometer, air flow is found by wind tunnel.
-5. How to control the quality of products in your company.
Answer: 100% total testing before each fan dispatched.
