Price: | US $ 1.00kg |
---|---|
Trade Terms: | FOB,CFR,CIF |
Min Order: | 10/Ton |
Pay Type: | L/C,T/T |
Prod Model: | S-02 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Certificate: | ISO9001, As4084, CE, SGS |
Material: | Steel |
Structure: | Rack |
Mobility: | Adjustable |
Height: | 0-5m |
Closed: | Open |
Development: | Conventional |
Serviceability: | Common Use |
Type: | Pallet Rack |
Weight: | up to 1, 000 Kgs Udl/Level |
Pallet racking systems are the most common form of storage rack. Pallets of materials are placed directly on the rack system by a forklift. Each load in pallet racks is readily accessible, making the 100% selective storage rack systems are both economical and efficient. Pallet rack designs come in numerous configurations to handle any storage need and can be easily expanded as your company grows. They are well built and extremely durable. Pallet rack systems are available in slotted, tear drop and structural.
1. Features: | 1)Color and size canbe adjusted according to your requirements; 2)Idealfor large quantityand bulk operation, andpalletracks; 3)Surface treatment:Epoxypowder coated or Galvanisedand color optional; 4)Easyto installand dismantle; 5)Availablewith light, medium, and heavycarrying capacities; 6)Highqualityand good appearance; 7)Themostcommonlyusedin allstorage systems for palletized goods; 8)Compatible with mosttypes of handlingequipment,Toachieve a varietyof size and weightof the trayquick access; 9)each layer carrying up to500-5000kg; 10)Thereliable and efficientservice before and after deal. |
2. Material: | High grade Q235B Steel |
3. Finish: | Powder Coated Finish or Galvanised |
4. Load Capacity & Dimension: | Loading capacity: 500-6000 kgs UDL/beam level. Height: 500-20000mm Depth: 400-1500mm Length: 1000-4000mm Specail sizes also avaiable to specific storage needs. |
5. Main Parts Specs: | 1) Uprights:55*47*1.5-2.0mm 86*60*1.5-2.0mm 90*70*1.5-2.0mm 100*70*1.5-2.0mm. 2) Box beams: 80*50*1.5-2.0mm, 100*50*1.5-2.0mm, 120*50*1.5-2.0mm, 140*50*1.5-2.0mm, 160*50*1.5-2.0mm,etc. 3) Horizontal & diagonal bracings, upright footplates, safety locking pins, bolts & nuts, anchors and all necessary components. |
6. CE certified. | BaiKai storage metal rack, CE certified, is designed and manufacturered to European Racking Code FEM 10.2.02, the Australian Standard - Steel Storage Racking AS4084-2012, and American racking standards. |
7. Package | The beams, and upright posts are separate packed by bubble film, can be also carton according to customer's requirement.Shelves packed in carton. Safe for long-distance transportation.Container load:50-100 sets per 1x20ft container, 100-160 per 1x40ft container |
8.MOQ | 10 tons |
9. Payment term | 30% deposit , the balance against the copy of B/L |
10. Loading port | Nanjing,Shanghai |
11. Supply ability | 6000 tons per month |
10. Quick Delivery. | Within 15 days for ordinary order quantity. Big production capacity allow us in a position to make quick delivery |
