Cylindrical Cap Shape Fuse Holder Rt18-125

Cylindrical Cap Shape Fuse Holder Rt18-125
Price: US $ 1/Piece
Min Order: 1/Piece
Pay Type: T/T,Western Union,Paypal,Money Gram
Prod Model: RT18-125
Voltage: 500/690V
Current: 2-160A
Use: Gg / Gl
Breaking Capacity: High
Type: Current Fuse
Usaga: Low Voltage

Product Description



1.  Application

    This series fuse is suitable for AC 50Hz, rated voltage to 600V, rated current to 125A. It is mainly used for protecting the electrical circuit against overload and short-circuits (gG/gL). Because of different melting tablets, it also may derive for rotecting the semiconductor device and others complete set installment from short-circuit (aR/gR/gs) as well as the electric motor from short-circuit (aM). The rated breaking capacity is to 100KA. They conform to national standard GB13539 and international electrical committee standard IEC60269.


2.Construction Feature

This series of fuse consists of fuse link and fuse base. The variable cross-section fuse body made by pure copper piece (or copper wire, silver wire, silver piece) is sealed in the fusion tube which is made by the high strength porcelain or epoxy glass cloth pipe, there is full of the high-purity quartz sand processed after chemistry to take the extinguishing of arc medium in the tube. The two sides of the fuse use the spot welding to reliably connect with the end plate and to form the cylindrical cap shape structure. Fuse base suppressed by the resin or plastic casing fitted with contacts and contains the fusion pieces, the connection made by riveting as the support of the appropriate size fuse body parts. This series of fuse has many merits such as small in size, convenient for installation, safe in usage, beautiful in appearance and so on.



3. Principle Technical Parameter



fuse base model

matched with fuse body measurement

rated vltage(V)

rated current(A)


overall dimension/size(mm)



A1

A2

B

H1

H2

Φd

RT18-125X/1P

22.2×58

380/500

125



126

134

36

78

104

-

RT18-125X/2P

22.2×58

380/500

125



126

134

72

78

104



RT18-125X/3P

22.2×58

380/500

125



126

134

108

78

104



RT18-125X/4P

22.2×58

380/500

125



126

134

144

78

104







Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.
