Double Side Wooden Cover Plain Back Supermarket Shelf

Prod Model:	HBE-SR-H
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color:	Powder Coating
Size:	Customized Double Side Shelf
OEM:	Can Be as Request
Finish:	Powder Coating
Design:	Supermarket Shelf
Colour:	Pantone Color Available
Place:	Supermarket Shelf
Back:	Plain Back Panel
Layer:	3-8 Layers
Model:	Main Shelf
Material:	Steel
Style:	Back Hole Style
Side Number:	Single Sided
Weight:	Middle Weight
Rotary:	Fixed
Usage:	Supermarket
Customized:	Customized

Product Description

Supermarket shelf (Perforated back panel)

Perforated backboard shelf for supermarket, Pegboard supermarket shelf, metal gondola shelving, punching back shelf, supermarket display shelf, punched backboard shelf/rack, supermarket rack/display stand.
1. Detailed specification:
Specification
Double-sided: 1200*900*1800mm
Single-sided: 1200*500*1800mm
End shelf: 900*450*1800mm
Size of upright/post
30*60*(1.5-2.0)mm/40*60*1.8(2.0)mm/40*80*(1.8-2.5)mm
Thickness of bracket
1.5-2.5mm. L: 300-500mm.
Thickness of shelf
0.5-1.0mm. L: 890/960/1160*300/350/400/450/500/550mm
Thickness of perforated back board/panel
0.7-1.0mm. L: 885/950/1150*147/297/347mm
Capacity
30-180KG/layer
Layer(s)
3/4/5layers

Punched backboard shelf

2. Advantages & Features:
1) Color and size can be adjusted according to your requirements;
2) Surface treatment: Epoxy powder coated, dry quickly providing a
Tough, protective coating with excellent hardness, anti-corrosion, low
Volatility and water clean up, more heat resistant, and color optional;
3) Easy to install and dismantle;
4) Available with light, medium, and heavy carrying capacities;
5) High quality and good appearance;
6) The most commonly used in all supermarket systems;
7) Each layer carrying up to 30-150kg.
8) The reliable and efficient service before and after deal.

3. Terms of Packing and Delivery
Packing
The upright/posts and brackets are separately packed by
Bubble film, can be also carton according to customer's requirement. Shelves,
Backboards packed in carton. Safe for long-distance
Transportation.
MOQ
50sets
Delivery time
Within 25workday upon receipt of the deposit or
Original L/C.
Payment term
30% deposit, the balance against copy of B/L
Or 100% irrevocable L/C at sight
Loading port
Shanghai, China
Supply Ability
1000 pieces per week.
Quotation
Please offer us the following details, so we can give you the exact quotation:
1) Size of your supermarket;
2) Full details of size: W*D*H;
3) The quantity bays you need;
4) How many layers/set you want;
5) Loading capacity of each layer;
6) RAL color you require;
7) Drawing (if available).
