Prod Model: |
NGC81104 |
Various Size: |
Various Color |
Samples: |
3-7days |
Min. Radius: |
400mm |
Type: |
Tempered |
Color: |
Clear, Green, Bronze, Blue, Silver, Gold, etc |
Technique: |
Tempered Curved Glass |
Thickness: |
3-22mm |
Quality: |
Top |
Warranty: |
10years |
Delivery Time: |
3-5weeks |
Shape: |
Curve |
Appearance: |
Bent Tempered |
Standard: |
GB 11614-89 |
Steel Degree: |
Tempered Glass |
Thickness Of Flat Tempered Glass: |
6MM |
Thickness Of Curve Tempered Glass: |
6MM |
Fragment State: |
Ⅱ |
Technics: |
Physically Tempered |
Flatness: |
High Class |
Usage: |
Window,Door |
Product Description
EN IGCC Standard Large Size Flat Curved Bent Toughened glass
What is it?
Tempered glass also called toughed safety glass, has a very good performance of anti-curve, anti-hitting, 3 to 6 times stronger than normal glass. It can afford pressure over 95MPa on the surface. It has high stability even under temperature changing from 200 to 300. While normal glass can only afford change of 70-100. It becomes small sand shape if is broken under big force, which guarantee safety and less loss.
Bent tempered glass for curtain wall adopts the similar process with tempered glass, but before the cooling process, using the external power bent the glass to a proper radian according the requirement, its wind pressure resistance is better than flat tempered glass and other kinds glass for the special shape. It widely use in esthetics architecture field for the beautiful appearance.
Advantages:
Safety performance: Glass will appearance hurtless obtuse angles when breakage.
Strength performance: Four times more than ordinary glass.
Heat stability: Three times more than ordinary glass, could bear the temperature change about 200 °C.
Application:
Handrails and Spiral Staircases
Commercial/Residential Windows
Curtain Walls and Storefronts, etc.
Specification:
We can provide bending glass according to customers' requirements
Max. Size: 5000mm*3660mm
Min. Size: 100mm*100mm
Min. Radius: 450mm
Thickness Range: 3mm 4mm 5mm 6mm 8mm 10mm 12mm 15mm 19mm 25mm
Quality Standard:
In accordance with ASTM C1464-00 Standard for curved /bent glass.
Pass Chinese Safety Glass Compulsory Certification (CCC), CSI.
Specification
Product Name | Safety Tempered Glass |
Glass thickness | 4mm, 5mm, 6mm, 8mm, 10mm, 12mm, 15mm,19mm |
Size | Max. Size | 3600mm * 18000mm |
Min. Size | 200mm * 300mm |
Color | Neutral, light blue, ford blue, dark blue, ocean blue, light gray, blue gray, light green, dark green, gold, bronze, etc |
shape | Flat or Curved tempered glass |
Quality Standard | Chinese standard |
EN 12150, European Standard |
ASTM C1038, American standard |
Available glass | PPG Guardian AGC Saint Gobain Low e tempered glass, reflective tempered glass, clear toughened safety glass, Starphire low iron tempered glass, and so on |
