Hot Selling Heavy-Duty Metal Storage Shelves

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Export Markets:	Global
Material:	Steel
Structure:	Rack
Mobility:	Adjustable
Closed:	Open
Development:	Conventional
Serviceability:	Common Use
Height:	2m-15m
Weight:	1000-4000 Kgs/Level

Product Description

Heavy-Duty Storage Shelves/Shelf/Shelving

Heavy shelf storage system is the most commonly used goods of all types of enterprises. Many varieties suitable for storing large quantities of all types of cargo carrying capacity. Each floor in the uniform distribution of the state carrying up to 800KG-5000KG, particularly suitable for use Stacker and forklift operation use, the height of 75mm each be adjusted up and down, the actual needs of the non-standard production according to customer requirements and warehousing.


Our Storage Rack Advantages

1. Color and size can be adjusted according to your requirements.
2. Upright and beam is formed by high-quality cold rolled steel, with an omega shaped section to make sure they are very strong.
3. Box beam or step beam used. Beam can be freely adjusted by pitch 50mm or 75mm.
4. Connection of the upright and beam is by wedging, equipped with safety pin to make sure of the safety.
5. Rich accessories: Upright protector, guide rail, frame barrier, row spacer, wire decks, steel shelf, etc.
6. Stable structure, large loading capacity, convenient sorting.
7. Compatible with most type of handling equipment and building structures.
8. First level pallets can be placed on the floor.
9. Easy to install and dismantle.

Our Advantages

1. High and stable quality.
2. Delivery timely.
3. Excellent rolling technology and patents

Services:

Our free services include consultations and sample CAD layouts of your proposed rack system. Don't hesitate to consider reviewing the racking systems on site or at our headquarters. Get the racking system you need at the best price guaranteed.

Remark:

We are very professional in producing various pallet racking, longspan shelving, cantilever racks, rivet shelving, drive in racks, steel mezzanine, carton flow racking and other related storage equipments.

Please don't hesitate to contact us, we are very confident to provide you with satisfying products!

Feature of Pallet racking
Meterial		High-quality  steel  from  BAO  Steel  Co.   Ltd.,   the  largest  steel  manufacturer  in  China.
Surface treatmet:		Podwer coating; Normal color(Orange or blue) or according to customer' s requirement.
Size	Height	2-11m (6.56-36.1ft), or according to customer' s requirements.
	Width	1.5-3.3m (4.92-10.82ft), or according to customer' s requirements.
	Length	0.8-1.2m (2.63-3, . 94ft), or according to customer' s requirements.
Thickness		Upright: 1.5-2.5mm; Beam: 1.5-2.0mm.
Spec. of upright		60X55mm, 70X55mm, 90X70mm,   105X70mm, 120X90mm, etc.
Spec. of beam		80X50mm,     90X50mm,   100X50mm, 110X50mm,   120X50mm,   140X50mm, etc.
Loading capacity (per layer)		700-4000kg (1 543-8 818lb). Refer to below sheet 2 for more details.
Layer		2-5. or according to customer' s reqirement.
Packing detial:		Experienced export packing (uprights and beams' both end with cardboard, then outside bundled tightenly with plastic belts, safe for long-distance transportation) also we can follow your requirement.
Delivery detial:		10-15 ton per 1x20ft container, 15-25 ton per 1x40ft container. 15-20 workdays after received the deposits.
