Price: | US $ 970-1200/Piece |
---|---|
Min Order: | 1/Piece |
Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
Prod Model: | BLX-10 |
---|---|
Tube Frequency: | 70kv |
Colors: | White, Blue, Pink |
Warranty: | 5 Years for Toshiball Ball Head and 1 Year for The |
Ball Head: | Toshiba Ball Head |
Weight: | 2kg |
Tube Current: | 1mA |
Time Setting Range: | 0.5-1.2s |
Delivery Time: | 5 Days |
Experiences: | First Leading Manufacturer |
Mimimum Order: | 1 Sets |
Type: | X-Ray Equipment |
Specification:
1. 5 years warranty for Toshiba ball head
2. Special material--Lead
3. Low radiation
4. Much smaller and lighter
5. Lithium battery
6. Can be used with sensor
Characteristic:
1.No protective operation room is needed when installing the complete machine;
2.Flexible adjustment the position and angle of hand piece,simple and easy to handle;
3.Develop dental film in daylight, no darkroom need;
4.Compace in volume, light in weight, convenient for carrying;
5.Time is adjustable, high contrast of picture, imaging in focus;
6.Can be used with sensor;
7.Radiation leakage is in accordance with international standard(ICE601-1-3.1993)
8.More intelligent, easy to cooperate with three model
9. In small volume, big screen
10. Shot time in taking photos
Technical specification:
Product Parameters
a) The rated parameters of x-ray production device
1. Tube voltage: 70kv (fixed)
2.Tube current: 1MA (fixed)
3. High voltage generating circuit: High frequency switch
4. X-ray control method: Microprocessor control
5. Time setting range: 0.05-1.2 seconds
b) Weight: 1.95kg
c) Size: 215*140*160 mm
d) X-ray tubing
1. Type: bipolar fixed x-ray tube
2. X-ray tube Model: DG-073B-DC
3. The size of x-ray tube focal spot: 0.3*0.3mm
4. ANODE heating unit: 8.5Khu
5. Maximum tube voltage: 75Kv
6. Target angle: 21°
7. Total filtration: 1.6mmAL (Origin filtration: 0.8mmAL, Additional filtration: 1mmAL)
X-ray irradiation range: 73mm (roundness)
e) Useage voltage: battery DC16.8V
f) Charger: Input AC100-240V, Output: DC16.8V
