Price: | US $ 250/Piece |
---|---|
Trade Terms: | FOB,CFR,CIF |
Min Order: | 10/Piece |
Pay Type: | L/C,T/T,Western Union |
Prod Model: | YD-S025 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Storage Rack: | Tire Storage Rack |
Size: | L2500*W1000*H3000mm |
Shelf: | 3~6 Layers |
Color: | Any Color |
Finish: | Good Powder Coated |
MOQ: | 10PCS |
Loading Port: | Shanghai |
Certification: | ISO9001:2008&CE |
Material: | Steel |
Structure: | Rack |
Mobility: | Adjustable |
Height: | 0-5m |
Closed: | Open |
Development: | New Type |
Serviceability: | Common Use |
Weight: | 1000~3000kg/Layer |
item | specification L*W*H(mm) | post | beam | layer board | layer | load-bearing |
heavy duty rack | L2400*W1000*H2500mm(adjustable) | 70*90*2.0mm(adjustable) | 50*80*2.0mm(adjustable) | 0.7*0.8*1.0*1.5mm | 2-5 | 1000-3000kg/layer |
middle duty rack | L2000*W600*H2000mm(adjustable) | 40*80*1.0mm(adjustable) | 40*60*1.1mm(adjustable) | 0.5*0.4*0.35mm | 4 | 300-500kg/layer |
light duty rack | L1800*W500*H2000mm(adjustable) | 30*50*1.0mm(adjustable) | 30*50*1.0mm(adjustable) | 0.5*0.35*0.27mm | 4 | 100-200kg/layer |
specification | L2500*W1000*H3000~6000mm(adjustable) special sizes also available to specific storage needs . |
main size | 1)post: 70*100*2.0mm;ect 2)beam: 50*140*2.0mm; ect 3)layer board: 1.0mm;ect 4)horizontal & diagonal braces, upright footplates, safety locking pins, bolts & nuts, anchors and all necessary components. |
layer | 2~5 (adjustable) |
load-bearing | 1000~3000kg/layer |
materials | cold roll steel |
color | different color can be available |
finish | good powder-coated |
certification | CE&ISO9001:2008 |
MOQ | 10 pieces |
loading port | Shanghai |
transportation | select different ways refers to the quantity or the opinion of trade company |
delivery | within 7-15 days after we get deposit, much depends on the quantity your order. We promise delivery on time |
terms of payment | T/T(30% T/T in advance, balance should be paid before shipping) Western Union |
packing | board in carton, upright and beam in plastic bubble film (quality packing make sure goods safety) |
samples | sample supply is Ok, but you need to pay for the sample cost and freight cost; |
features | 1) pallets can be located, accessed and moved individually 2) rapid handling of almost all types of pallet goods. 3) infinitely adjustable and offering a wide range of options and components to accommodate specialized needs. 4) maximizes space use in any warehouse configuration while retaining optimum product accessibility. 5) strength and rigidity prevents compression damage to goods. 6) bottom level of pallets can be stored on the floor, lowering structure costs |
remark | please offer us the following information in details when you place you order 1)full details of the size L*W*H and the layer board; 2)the color you required; 3)how many pieces you want; 4)the surface treatment. |
