4-19mm Clear Toughened Glass Pool Fence

Prod Model:	Toughened Glass
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Item:	4-19mm Clear Toughened Glass Pool Fence
Standard Size Of Float Glass:	2134X3300mm;1830X2440mm;2134X3660mm;etc
Type:	Tempered
Color:	Clear
Technique:	Tempered Glass
Thickness:	4-19mm
Certificate:	CE,ASTM,Csi
Delivery Time:	1-2weeks
Payment Term:	Tt,L/C at Sight
Sample:	3-5days
Shape:	Flat
Appearance:	Flat Tempered
Standard:	GB/T 9963-1998
Steel Degree:	Tempered Glass
Thickness Of Flat Tempered Glass:	8MM
Fragment State:	Ⅱ
Flatness:	High Class
Usage:	Building

Product Description

4-19mm Clear toughened glass pool fence is made by forming compressive stress on the surface of the glass and heating the glass up to its intenerating temperature and then make the glass uniform cooling quickly. During the process of cooling, the exterior part of the glass is solidified because of the rapid cooling, while the interior part of the glass shrinks because of slow cooling, then forming compressive stress on the surface of the glass and tensile stress inside the glass, thus improving the intensity and heat stability of the glass.

Safety performance: 4-19mm Clear toughened glass pool fence will appearance hurtles obtuse angles when breakage.
Strength performance: Four times more than ordinary glass.
Heat stability performance: Three times more than ordinary glass, could bear the temperature change about 200° C.


Glass Processing Standard

We,NORTHGLASS INDUSTRIA glass are consistent with GB/T11944,Chinese Standard EN1279,European standard ASTME2190,American Standard, Australia CSI and CE certificates. As below:


Float Glass

GB11614; BS EN572-2European standard;ASTM C 1036 USA standard

Flat tempered glass

ASTM C1048;EN12150;CCC;IGCC;CSI

Curved tempered glass

ASTM C1464

Heat soak tempered glass

EN14179 orAPP-37

Insulating glass

ASTM E2190;IGCC;BS;GB11944 etc

Laminated glass

ASTM C1172;BS952,British standard;IGCC,USA standard;AS/NZ2208 Australian standard;GB,Chinese standard

Coating glass

ASTM C1376;

Reflective glass

GB T18915.1 standard; IGCC standard

Heat strengthened glass adopt the similar process, but the cooling course is longer than tempered glass. So the compressive stress is not so big like tempered glass and the flatness is more perfect.
Safety performance: Not easy to breakage, and could remain in frame when breakage.
Strength performance: Twice than ordinary glass
Heat stability performance: Could resist heat effectively, and avoid heat breakage
Standard: EN1863-1; ASTMC 1048-976

Curved tempered glass adopt the similar process with tempered glass, but before the cooling process, using the external power bent the glass to a proper radian according the requirement, its wind pressure resistance is better than flat tempered glass and other kinds glass for the special shape. Curved tempered glass/bended glass/bent glass widely use in esthetics architecture field for the beautiful appearance.

Safety performance: Glass will appearance hurtles obtuse angles when breakage.
Strength performance: Four times more than ordinary glass.
Heat stability: Three times more than ordinary glass, could bear the temperature change about 200 ° C.

Applications:
4-19mm Clear toughened glass pool fence can be used in the constructions, automobile, train, ship, furniture, automatic door, escalator, microwave oven, refrigerator, etc. And irregular shape glass is made by heating annealed glass in a furnace to 690 degree. Progressing from the annealing furnace, then the glass cooled quickly with jets of cold air, inducing compressive stress to the surface while the center remains tensile.

4-19mm Clear toughened glass pool fence is extensively used in shower door glass, fencing glass, revolving door glass, high quality furniture glass and architectural situations.

Specifications:

Max. Size: 2600mm*2440mm
Min. Size: 300mm*300mm
Min. Radius: 450mm
Thickness Range: 4mm-25mm

Competitive Advantage:
4-19mm Clear toughened glass pool fence has a very good performance of anti-curve, anti-impact intensity, 3 to 6 times better than normal glass. 4-19mm Clear toughened glass pool fence can afford pressure over 95MPa on the surface. 4-19mm Clear toughened glass pool fence has high stability even under temperature change of 200-300 centi-degrees, while normal glass can only afford change of 70-100 centi-degrees. 4-19mm Clear toughened glass pool fence becomes small sand shape if tempered glass is broken under big force, which guarantees safety and less loss.

Our 4-19mm Clear toughened glass pool fence is most famous in glass industry of China. We process irregular shape glass at high accuracy with good quality. Irregular shape glass can be further processed into insulated glass, tempered and laminated glass, etc.
