8mm Curved Glass for Exterior Curtain Wall
| Price: | US $ 6/Square Meter |
|---|---|
| Min Order: | 50/Square Meter |
| Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: | NGC2205 |
|---|---|
| Various Size: | Various Color |
| Samples: | 3-7days |
| Min. Radius: | 400mm |
| Type: | Tempered |
| Color: | Clear, Green, Bronze, Blue, Silver, Gold, etc |
| Technique: | Tempered Curved Glass |
| Thickness: | 3-22mm |
| Quality: | Top |
| Warranty: | 10years |
| Delivery Time: | 3-5weeks |
| Shape: | Curve |
| Appearance: | Bent Tempered |
| Standard: | GB 11614-89 |
| Steel Degree: | Tempered Glass |
| Thickness Of Flat Tempered Glass: | 6MM |
| Thickness Of Curve Tempered Glass: | 6MM |
| Fragment State: | Ⅱ |
| Technics: | Physically Tempered |
| Flatness: | High Class |
| Usage: | Window,Door |
Product Description
8mm Curved Glass For Exterior Curtain WallCurved tempered glass also called bent tempered glass. It represents the future trend in construction and facade materials and has seen rapid growth in worldwide demand.
What is it?
Bent tempered glass for curtain wall adopts the similar process with tempered glass, but before the cooling process, using the external power bent the glass to a proper radian according the requirement, its wind pressure resistance is better than flat tempered glass and other kinds glass for the special shape. It widely use in esthetics architecture field for the beautiful appearance.
Advantages:
Safety performance: Glass will appearance hurtless obtuse angles when breakage.
Strength performance: Four times more than ordinary glass.
Heat stability: Three times more than ordinary glass, could bear the temperature change about 200 °C.
Specifications of tempered curved glass:
Thickness of curved tempered glass: 3mm-22mm
Max: 3300mm*12800mm Min: 180mm*180mm
Min. Radius: 400mm
Tempered curved glass adopt the similar process with tempered glass, but before the cooling process, using the external power bent the glass to a proper radian according the requirement, its wind pressure resistance is better than flat tempered glass and other kinds glass for the special shape.
Applications:
Curved tempered glass is safety glass, extensively applied in the places which has critical request of high mechanical strength and safety, such as glass door, curtain wall of building, indoor partition, elevator, showcase, door and window of building, furniture and household appliance etc.
Curved tempered glass/bended glass/bent glass widely use in esthetics architecture field for the beautiful appearance.
Parameters:
1. Visible Light Transmittance ≥ 91%
2. Iron content: ≤ 120ppm Fe2O3
3. Density: 2.5g/CC
4. Yong's Module: 73Gpa
Tensile Strength: 42Mpa
Competitive Advantage:
1. The anti-impacting performance and anti-bending performance of curved tempered glass are 3-5 times higher than ordinary glass.
2. Curved tempered glass breaks into granules in case of strongly knocked, so no hurt would be caused.
3. Deflection angle of curved tempered glass is 3-4 times larger than that of float glass with same thickness. When there is load on curved tempered glass, its maximum tensile stress does not locate on the glass surface as float glass, but on the central point of glass sheet.
