Price: | Negotiable/Set |
---|---|
Min Order: | 20/Set |
Pay Type: | L/C,T/T |
Prod Model: | DIR201702 |
---|---|
Material: | Steel |
Structure: | Rack |
Mobility: | Adjustable |
Height: | 5-15m |
Closed: | Open |
Development: | New Type |
Serviceability: | Common Use |
Weight: | 500-4000 |
The structure of URGO heavy duty pallet rack includes uprights and beams, According to the customer's actual pallet load capacity and warehouse size, select the column and beam specifications, as well as increasing racking accessories.
Upright:
1. High load capacity up to 21000kg.
2. Frames include all the elements needed for assembly: bracing, feet and nuts & bolts.
3. Blue epoxy coated (RAL 5012/5015/5017).
4. Standard heights : From 2 to 11.5m.
5. Adjusted by 50/75mm pitch.
Column Profiles:
Column Specification (mm) | Thickness (mm) | Upright Loading (kg) |
W80 x D60 | 1.8-2.0 | 4000-6000 KG |
W85 x D67 | 1.8-2.3 | 7500-12500 KG |
W90 x D60 | 1.8-2.5 | 8000-10000 KG |
W90 x D70 | 1.8-2.5 | 10000-12000 KG |
W100 x D70 | 2.0-2.5 | 11000-14000 KG |
W120 x D95 | 2.3-3.0 | 17000-21000KG |
Beam:
1. High load capacity up to 5000kg.
2 .Manufactured with the highest quality steel Q235.
3. Orange epoxy coated (RAL 2004).
4. Lengths available: 1500/2000/2300/2700/3000/3300/3600/3900mm
5. Boltless connection with 3/ 4/ 5 connector hooks.
6. A security pins per beam to prevent accidental dislodgement.
7. Powder coating finish
Beam Profiles:
Loading (kg) Specification (mm) | The Length of Box Beam (mm) | ||||||||
1500 | 2000 | 2300 | 2500 | 2700 | 3000 | 3300 | 3600 | 3900 | |
80 x 50 x 1.5 | 3000 | 1740 | 1340 | 1160 | 1010 | ||||
90 x 50 x 1.5 | 4080 | 2350 | 1800 | 1645 | 1345 | 1010 | 850 | ||
100 x 50 1.5 | 2960 | 2260 | 1930 | 1680 | 1380 | 1040 | |||
110 x 50 x 1.5 | 2640 | 2250 | 1950 | 1600 | 1340 | 1140 | |||
120 x 50 x 1.5 | 3200 | 2730 | 2358 | 1930 | 1518 | 1379 | |||
140 x 50 x 1.5 | 3868 | 3330 | 2720 | 2370 | 2020 | ||||
160 x 50 x 1.5 | 4220 | 3690 | 2970 | 2600 | 2340 | ||||
160 x 50 x 1.8 | 4400 | 3420 | 3020 | 2590 | |||||
160 x 50 x 2.0 | 4130 | 4170 | 3320 | 2840 |
Loading (kg) Specification (mm) | The Length of P Box Beam (mm) | ||||||||
1500 | 2000 | 2300 | 2500 | 2700 | 3000 | 3300 | 3600 | 3900 | |
100 x 50 x 1.5 | 4470 | 2512 | 1900 | 1610 | 1380 | 1120 | 920 | ||
110 x 50 x 1.5 | 5484 | 3085 | 2332 | 1974 | 1693 | 1371 | 1133 | 952 | |
120 x 50 x 1.5 | 3910 | 2957 | 2503 | 2146 | 1738 | 1436 | 1207 | 1030 | |
140 x 50 x 1.5 | 5722 | 4330 | 3662 | 3140 | 2543 | 2102 | 1766 | 1505 |
