Home LED Light Products High Quality 10mm Triple Glazed Glass Panel
High Quality 10mm Triple Glazed Glass Panel
| Price: | US $ 25/Square Meter |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 500/Square Meter |
| Pay Type: | L/C,T/T,Western Union,Money Gram |
| Prod Model: | Glass Panel |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material: | Silver Mirror |
| Thickness: | 3-12mm |
| Shape: | Square |
| Frame Material: | Metal |
| Folded: | Unfolded |
| Sides: | Single Sided |
| Special Function: | Waterproof |
| Finish: | Silver |
Product Description
Noval silver mirror is a highly durable mirror. The mirror is created by depositing a layer of silver onto glass, followed by a sheet of copper, which is then treated and proceed by one or more layers of highly resistant protective paint. The innovative manufacturing process is more environmentally friendly and improves the overall durability and optical quality of the product.Advantages
Environmentally friendly
Transforms internal spaces with brilliance and perspective
Optical quality and durability
Easy processing and installation
Increase the feeling of space and enhances interiors
Processed product variations, suitable for cutting into regular and more unusual shapes, after cutting, it can be drilled and edgeworked (beveled, pencil edge, flat edge etc), Like traditional mirrors, wall mirror, decorative mirror, safety mirror, furniture mirror. The front face of the mirror can be customized by means of sandblasting or engraving to create patterns, logo and graphics etc
Application
Environmentally friendly
In communal areas in office or apartment blocks: Entrance halls, lifts or landings
In shopping centers and retail stores
In bars, restaurants, clubs, theatre sand cinemas
In public buildings, offices, clinics and hospitals
To be used as framed or unframed mirrors
For paneling on walls, doors or pillars
In furniture (tables, cupboard doors, shelves etc
ProductionRange
Thickness: 1.1- 8mm
Mirror color: Clear, Bronze, Green, Blue, Pink etc.
Back paint color: Grey, Green, Milk white, Red, Blue etc.
Regular Size:
1.1mm 914*1220mm, 1000*1000mm
2mm 1600*2200mm, 1500*2000mm.
3mm1830*2440mm, 2134*3050mm, 2134*3300mm.
4mm 1830*2440mm, 2134*3300mm, 2250*3300mm, 2134*3660mm.
5mm 1830*2440mm, 2134*3300mm, 2250*3300mm, 2134*3660mm, 2250*3660mm, 2440*3660mm.
6mm1830*2440mm, 2134*3300mm, 2250*3300mm, 2134*3660mm, 2250*3660mm, 2440*3660mm.
If your order quantity is more than 10000 SQM, we can do the size according to customized size, for the best finished rate.
Silver Mirror Installation Guidelines
The wall should be perfectly smooth and flat.
If the installation surface is too irregular, fix a plywood panel before installing the glass.
Do not install on damp walls.
Avoid installing close to heat sources (heating, cookers etc).
There are two possible fixing methods.
Adhesive: Using compatible mirror adhesives (test reaction of the glue on the lacquer/silver if in doubt about whether the glue is neutral), or double-sided adhesive tape.
Mechanical fixing: Using mirror rail (can be used to mask irregularities in the wall), fixing brackets or 'J'-section trim.
The gap between two panels should normally be 3mm.
The adhesive should be applied according to the manufacturer's recommendations, and also allow for the circulation of air behind the mirror; For example as vertical pencil size beads.
| 1.1mm | 914*1220mm, 1000*1000mm |
| 2mm | 1600*2200mm, 1500*2000mm |
| 3mm | 1830*2440mm, 2134*3050mm, 2134*3300mm |
| 4mm | 1830*2440mm, 2134*3300mm, 2250*3300mm, 2134*3660mm. |
| 5mm | 1830*2440mm, 2134*3300mm, 2250*3300mm, 2134*3660mm, 2250*3660mm, 2440*3660mm |
| 6mm | 1830*2440mm, 2134*3300mm, 2250*3300mm, 2134*3660mm, 2250*3660mm, 2440*3660mm. |
Beijing Northglass Technologies Co. Ltd, a leader in glass industry, has been engaged in the research, development, processing glass since 1987. Produce range includes: Laminated safety glass, tempered safety glass, low e insulated glass, reflective glass, silk screen printed glass(ceramic frit glass, enamalled glass), tempered glass, curved tempered glass, hot curved glass, heat strenghened glass, fire proof glass, bullet proof glass, ultra clear glass(low iron glass), etc for curtain wall shower doors, windows, facades and furniture applications.
By far, we have asset USD50 million. Our head quarter is in HongKong, and our 3 fabrication companies are in China mainland having more than 1, 000 employees, of whom over 46% is specialized techical personel. Our company covers more than 390.000sqm. We have massive elites working at each process of working, among whom, professional technicians are over 26% and employees with Bachelor's degree are over 93%.
Our glass pass Australian CSI certificates, US IGCC SGCC certificates, European CE certificates and Chinese national certificates. Now we are working with customers in over 100 countries. To help customer to better achieve their success is our aim. Welcome you work with us, and establish long term cooperation!
