SGS Approved Solid Heavy Duty Warehouse Pallet Racks
| Price: | US $ 800-950/Ton |
|---|---|
| Trade Terms: | FOB,CIF,EXW |
| Min Order: | 1/Ton |
| Pay Type: | L/C,T/T |
| Export Markets: | Global |
|---|---|
| Material: | Steel |
| Structure: | Rack |
| Mobility: | Adjustable |
| Closed: | Closed |
| Development: | New Type |
| Serviceability: | Common Use |
| Height: | 2m-15m |
| Weight: | 1000-5000kg/Layer |
Product Description
Solid Heavy Duty Pallet Racks/Pallet Racking/Warehouse Rack/Pallet Rack ManufacturerHeavy-duty storage rack is also called pallet rack, beam rack and storage shelf, they are most widely used which need to apply with forklift that can pick up freely any goods put on to the location with the feature of simply structure, easy operation, good storage and safety.
Heavy-duty beam racks can be used companied with different kinds of accessories, such as support bars, wire cages, steel pallets, wood pallets, steel meshes, etc, to meet different demands.
Our Storage Rack Advantages
1. Color and size can be adjusted according to your requirements.
2. Upright and beam is formed by high-quality cold rolled steel, with an omega shaped section to make sure they are very strong.
3. Box beam or step beam used. Beam can be freely adjusted by pitch 50mm or 75mm.
4. Connection of the upright and beam is by wedging, equipped with safety pin to make sure of the safety.
5. Rich accessories: Upright protector, guide rail, frame barrier, row spacer, wire decks, steel shelf, etc.
6. Stable structure, large loading capacity, convenient sorting.
7. Compatible with most type of handling equipment and building structures.
8. First level pallets can be placed on the floor.
9. Easy to install and dismantle.
Our Advantages
1. High and stable quality.
2. Delivery timely.
3. Excellent rolling technology and patents
4. The whole set of perfect production process. (Cutting, roll forming, welding, galvanized, bending, punching machine, powder coated, assembly etc. )
Our normal standard type storage racks as below sheet:
Refer to the sheet, we have several normal standard types for your choice.
If there are not suitable one for you, we also accept your customized design.
Frame | Height (2-13m) | Depth (600-1,400mm) |
| Upright section: 80x60; 90 x 70; 100 x 65; 120 x87mm | ||
| Thickness: 2.0/2.3/2.5/3.0mm | ||
| Beam | Length (1200-4000mm) , popular size: 2300,2500,2700,3200,3600mm | |
| Beam section: 80 x 50; 100 x 50;110x50; 120 x 50; 140 x 50mm | ||
| Thickness: 1.4--1.5mm | ||
| Load capacity | 1-4Tons/Layer | |
| Others | - Pitch: 75mm - Delivery time: 14-20days - Payment term. T/T or L/C at sight - Necessary accessories: free(bolts & nuts, base plate, etc) - Packing: stretch film & carton - Surface treatment: powder coated, galvanization - Production capacity: 3000T/month - Available in various colors/specifications/sizes | |
